Point List Report

So you go to create a report using the Toolbox and the Point List Civil 3D puts out isn’t in order. Well it is in order, the order created, but you want them to be in a more logical numerical order. What to do? Well if you were me you’d do this.

Open the file that controls the report in Notepad (or other text editor), in this case it’s:

C:\ProgramData\Autodesk\C3D 2011\enu\Data\Reports\xsl\pointlist.xsl

Next we need to tell the report to sort the list before it process the points. For this report the location is right below this line:

<xsl:for-each select="//lx:CgPoint[not(@pntRef)]">

A quick internet search for xsl and sort, gives us the information we want. To sort the list we need to add these lines under the above line:

<xsl:sort select="@name"
data-type="number"/>

The report will now run with the point list in order. If we want the list sorted by another field, then change @name to the desired field.
